  *	@file    main.c
  * @author  Florian MAZEN
  * @version V1.0
  * @date    06/26/2010
  * @brief   Main
  */

#include <stm32f10x.h>
#include <stdio.h>

void RCC_Configuration();

/**
  * @brief  Main program.
  * @retval None
  */
int main()
{
	/* Configure the system clocks */
	RCC_Configuration();

	while (1)
	{
	}
}

/**
  * @brief Configures the different system clocks.
*/
void RCC_Configuration()
{
  /* RCC system reset(for debug purpose) */
  RCC_DeInit();
}

#ifdef  USE_FULL_ASSERT
/**
  * @brief  Reports the name of the source file and the source line number
  *         where the assert_param error has occurred.
  * @param  file: pointer to the source file name
  * @param  line: assert_param error line source number
  */
void assert_failed(uint8_t* file, uint32_t line)
{
  /* User can add his own implementation to report the file name and line number,
     ex: printf("Wrong parameters value: file %s on line %d\r\n", file, line) */

  /* Infinite loop */
  while (1)
  {
  }
}
#endif

/**
  *	@file    stf_syscalls_minimal.c
  * @author  Florian MAZEN
  * @version V1.0
  * @date    06/26/2010
  * @brief   newlib syscall declaration
  */

#include <stdlib.h>
#include <stdio.h>
#include <errno.h>
#include <time.h>
#include <sys/stat.h>

// Function declaration.
void _exit(int i);
int _open(const char *name, int flags, int mode);
int _read(int file, char *ptr, int len);
int _write(int file, char *buffer, unsigned int count);
int _lseek(int file, int ptr, int dir);
int _fstat(int file, struct stat *st);
int _link(char *old, char *new);
int _unlink(char *name);
int _stat(char *file, struct stat *st);
int _close(int file);
int _execve(char *name, char **argv, char **env);
int _fork();
int _getpid();
int _isatty(int file);
int _kill(int pid, int sig);
caddr_t _sbrk(int incr);
int times(struct tm *buf);
int _wait(int *status);

#undef errno
extern int errno;
char *__env[1] = {0};
char **__environ = __env;
extern unsigned int _sheap;
extern unsigned int _eheap;
static caddr_t heap = NULL;


// Function definition.

void _exit(int i)
{
	while (1);
}

int _write(int file, char *buffer, unsigned int count)
{
	return -1;
}

int _close(int file)
{
	return -1;
}

int _fstat(int file, struct stat *st)
{
	st->st_mode = S_IFCHR;
	return 0;
}

int _isatty(int file)
{
	return 1;
}

int _lseek(int file, int ptr, int dir)
{
	return 0;
}

int _read(int file, char *ptr, int len)
{
	return 0;
}

caddr_t _sbrk(int incr)
{
	caddr_t prevHeap;
	caddr_t nextHeap;

	if (heap == NULL)
	{ // first allocation
		heap = (caddr_t) & _sheap;
	}

	prevHeap = heap;

	// Always return data aligned on a 8 byte boundary
	nextHeap = (caddr_t) (((unsigned int) (heap + incr) + 7) & ~7);

	// Check enough space and there is no collision with stack coming the other way
	// if stack is above start of heap
	if (nextHeap >= (caddr_t) & _eheap)
	{
		errno = ENOMEM;
		return NULL; // error - no more memory
	}
	else
	{
		heap = nextHeap;
		return (caddr_t) prevHeap;
	}
}

int _open(const char *name, int flags, int mode)
{
	return -1;
}

int _link(char *old, char *new)
{
	errno = EMLINK;
	return -1;
}

int _unlink(char *name)
{
	errno = ENOENT;
	return -1;
}

int _stat(char *file, struct stat *st)
{
	st->st_mode = S_IFCHR;
	return 0;
}

int _execve(char *name, char **argv, char **env)
{
	errno = ENOMEM;
	return -1;
}

int _fork()
{
	errno = EAGAIN;
	return -1;
}

int _getpid()
{
	return 1;
}

int _kill(int pid, int sig)
{
	errno = EINVAL;
	return (-1);
}

int times(struct tm *buf)
{
	return -1;
}

int _wait(int *status)
{
	errno = ECHILD;
	return -1;
}

/*
Default linker script for STM32F10x_512K_64K
Copyright RAISONANCE S.A.S. 2008

Modified for High Density devices
by Francois Gervais, August 2009
Modified for C++ support with the help of generic.ld
from CodeSourcery G++ Lite
by Francois Gervais, Septembre 2009

Modifications for F4FEZ templates 2010
*/

/* include the common STM32F10x sub-script */

/* Common part of the linker scripts for STM32 devices*/


/* default stack sizes.

These are used by the startup in order to allocate stacks for the different modes.
*/

__Stack_Size = 1024 ;

PROVIDE ( _Stack_Size = __Stack_Size ) ;

__Stack_Init = _estack  - __Stack_Size ;

/*"PROVIDE" allows to easily override these values from an object file or the commmand line.*/
PROVIDE ( _Stack_Init = __Stack_Init ) ;

/*
There will be a link error if there is not this amount of RAM free at the end.
*/
_Minimum_Stack_Size = 0x100 ;


/* include the memory spaces definitions sub-script */
/*
Linker subscript for STM32F10x definitions with 512K Flash and 64K RAM */

/* Memory Spaces Definitions */

MEMORY
{
  RAM (xrw) : ORIGIN = 0x20000000, LENGTH = 64K
  FLASH (rx) : ORIGIN = 0x08000000, LENGTH = 512K
  FLASHB1 (rx) : ORIGIN = 0x00000000, LENGTH = 0
  EXTMEMB0 (rx) : ORIGIN = 0x00000000, LENGTH = 0
  EXTMEMB1 (rx) : ORIGIN = 0x00000000, LENGTH = 0
  EXTMEMB2 (rx) : ORIGIN = 0x00000000, LENGTH = 0
  EXTMEMB3 (rx) : ORIGIN = 0x00000000, LENGTH = 0
}

/* higher address of the user mode stack */
_estack = 0x20010000;



/* include the sections management sub-script for FLASH mode */

/* Sections Definitions */

SECTIONS
{
    /* for Cortex devices, the beginning of the startup code is stored in the .isr_vector section, which goes to FLASH */
    .isr_vector :
    {
		_stext = .;
		. = ALIGN(4);
        KEEP(*(.isr_vector))            /* Startup code */
		. = ALIGN(4);
    } >FLASH

    /* for some STRx devices, the beginning of the startup code is stored in the .flashtext section, which goes to FLASH */
    .flashtext :
    {
		. = ALIGN(4);
        *(.flashtext)            /* Startup code */
		. = ALIGN(4);
    } >FLASH

    /* the program code is stored in the .text section, which goes to Flash */
    .text :
    {
	    . = ALIGN(4);

        *(.text .text.* .gnu.linkonce.t.*)
    	*(.plt)
    	*(.gnu.warning)
    	*(.glue_7t) *(.glue_7) *(.vfp11_veneer)

    	*(.ARM.extab* .gnu.linkonce.armextab.*)
    	*(.gcc_except_table)

    } >FLASH



    .eh_frame_hdr : ALIGN (4)
	{
		KEEP (*(.eh_frame_hdr))
	} >FLASH
	.eh_frame : ALIGN (4)
	{
		KEEP (*(.eh_frame))
	} >FLASH
	/* .ARM.exidx is sorted, so has to go in its own output section.  */
	__exidx_start = .;
	.ARM.exidx :
	{
		*(.ARM.exidx* .gnu.linkonce.armexidx.*)
	} >FLASH
    __exidx_end = .;

    .rodata : ALIGN (4)
	{
		*(.rodata .rodata.* .gnu.linkonce.r.*)

		. = ALIGN(4);
		KEEP(*(.init))

		. = ALIGN(4);
		__preinit_array_start = .;
		KEEP (*(.preinit_array))
		__preinit_array_end = .;

		. = ALIGN(4);
		__init_array_start = .;
		KEEP (*(SORT(.init_array.*)))
		KEEP (*(.init_array))
		__init_array_end = .;

		. = ALIGN(4);
		KEEP(*(.fini))

		. = ALIGN(4);
		__fini_array_start = .;
		KEEP (*(.fini_array))
		KEEP (*(SORT(.fini_array.*)))
		__fini_array_end = .;

		. = ALIGN(4);
		KEEP (*crtbegin.o(.ctors))
		KEEP (*(EXCLUDE_FILE (*crtend.o) .ctors))
		KEEP (*(SORT(.ctors.*)))
		KEEP (*crtend.o(.ctors))

		. = ALIGN(4);
		KEEP (*crtbegin.o(.dtors))
		KEEP (*(EXCLUDE_FILE (*crtend.o) .dtors))
		KEEP (*(SORT(.dtors.*)))
		KEEP (*crtend.o(.dtors))

		. = ALIGN(4);
		_etext = .;
	    /* This is used by the startup in order to initialize the .data secion */
		_sidata = _etext;
	} >FLASH
    PROVIDE ( _sflash = _stext );
    PROVIDE ( _eflash = _etext );


    /* This is the initialized data section
    The program executes knowing that the data is in the RAM
    but the loader puts the initial values in the FLASH (inidata).
    It is one task of the startup to copy the initial values from FLASH to RAM. */
    .data  : AT ( _sidata )
    {
	    . = ALIGN(4);
        /* This is used by the startup in order to initialize the .data secion */
        _sdata = . ;

        KEEP(*(.jcr))
		*(.got.plt) *(.got)
		*(.shdata)
		*(.data .data.* .gnu.linkonce.d.*)

	    . = ALIGN(4);
	    /* This is used by the startup in order to initialize the .data secion */
   	 	_edata = . ;
    } >RAM



    /* This is the uninitialized data section */
    .bss :
    {
	    . = ALIGN(4);
        /* This is used by the startup in order to initialize the .bss secion */
        _sbss = .;

        *(.shbss)
		*(.bss .bss.* .gnu.linkonce.b.*)
		*(COMMON)

	    . = ALIGN(4);
	    /* This is used by the startup in order to initialize the .bss secion */
   	 	_ebss = . ;
	. = ALIGN(4);
    } >RAM

    /* Heap start after the last allocate block */
    PROVIDE ( _sheap = _ebss );
    PROVIDE ( _eheap = __Stack_Init );

    /* Heap end before the stack */

    /* This is the user stack section
    This is just to check that there is enough RAM left for the User mode stack
    It should generate an error if it's full.
     */
    ._usrstack :
    {
	    . = ALIGN(4);
        _susrstack = . ;

        . = . + _Minimum_Stack_Size ;

	    . = ALIGN(4);
        _eusrstack = . ;
    } >RAM
}

# Project name
PROJECT_NAME=Base

# Directory definition.
ST_LIB_DIR=./stm32-api/STM32F10x_StdPeriph_Driver
ARM_CMSIS_DIR=./stm32-api/CMSIS
STARTUP_FILE=./startup_stm32f10x_hd.S

# Directory for output files (lst, obj, dep, elf, sym, map, hex, bin etc.).
OUTDIR = build

# Toolchain definition.
CC=arm-none-eabi-gcc
OBJCOPY=arm-none-eabi-objcopy
OBJDUMP=arm-none-eabi-size
NM = arm-none-eabi-nm
LDSCRIPT=stm32_flash.ld

# should use --gc-sections but the debugger does not seem to be able to cope with the option.
LINKER_FLAGS=-Xlinker -o$(PROJECT_NAME).axf -Xlinker -M -Xlinker -Map=$(PROJECT_NAME).map -Xlinker --no-gc-sections

# Debugging format.
#DEBUG = stabs
#DEBUG = dwarf-2
DEBUG= gdb

# Optimization level, can be [0, 1, 2, 3, s].
# 0 = turn off optimization. s = optimize for size.
# (Note: 3 is not always the best optimization level. See avr-libc FAQ.)
OPT = s
#OPT = 2
#OPT = 3
#OPT = 0

# Compiler flag to set the C Standard level.
# c89   - "ANSI" C
# gnu89 - c89 plus GCC extensions
# c99   - ISO C99 standard (not yet fully implemented)
# gnu99 - c99 plus GCC extensions
CSTANDARD = gnu89

# Compiler flags definition.
CFLAGS=-g$(DEBUG) \
		-O$(OPT) \
		-std=$(CSTANDARD) \
		-T$(LDSCRIPT) \
		-I . \
		-I ./STCode \
		-I $(ST_LIB_DIR)/inc \
		-I $(ARM_CMSIS_DIR)/CM3/DeviceSupport/ST/STM32F10x \
		-I $(ARM_CMSIS_DIR)/CM3/CoreSupport \
		-D STM32F10X_HD \
		-D USE_STDPERIPH_DRIVER \
		-D VECT_TAB_FLASH \
		-D GCC_ARMCM3 \
		-D inline= \
		-D PACK_STRUCT_END=__attribute\(\(packed\)\) \
		-D ALIGN_STRUCT_END=__attribute\(\(aligned\(4\)\)\) \
		-mthumb \
		-mcpu=cortex-m3 \
		-ffunction-sections \
		-fdata-sections

ADEFS=-D STM32F10X_HD \
		-D USE_STDPERIPH_DRIVER \
		-D VECT_TAB_FLASH \
		-D GCC_ARMCM3 \
		-D inline= \
		-D PACK_STRUCT_END=__attribute\(\(packed\)\) \
		-D ALIGN_STRUCT_END=__attribute\(\(aligned\(4\)\)\)
# Assembler flags
ASFLAGS = $(ADEFS) -Wa,-adhlns=$(<:.S=.lst),-g$(DEBUG)
ALL_ASFLAGS = -mcpu=cortex-m3 -mthumb-interwork -I. -x assembler-with-cpp $(ASFLAGS)

# Source files
SOURCE=	main.c \
		stm32f10x_it.c \
		stf_syscalls_minimal.c \
		system_stm32f10x.c \

# ST Library source files.
ST_LIB_SOURCE= $(ARM_CMSIS_DIR)/CM3/CoreSupport/core_cm3.c \
		$(ST_LIB_DIR)/src/misc.c \
		$(ST_LIB_DIR)/src/stm32f10x_rcc.c \
		$(ST_LIB_DIR)/src/stm32f10x_gpio.c \

SOURCE+=$(ST_LIB_SOURCE)

# List of all source files without directory and file-extension.
ALLSRCBASE = $(notdir $(basename $(SOURCE)))

LIBS=

# List of all objects files.
OBJS = $(addprefix $(OUTDIR)/, $(addsuffix .o, $(ALLSRCBASE)))

# Define Messages.
# English
MSG_BEGIN = -------- begin --------
MSG_END = --------  end  --------

# Rules definition. ***********************************************************
all: begin gccversion $(OUTDIR)/$(PROJECT_NAME).bin end

$(OUTDIR)/$(PROJECT_NAME).bin : $(PROJECT_NAME).axf
	$(OBJCOPY) $(PROJECT_NAME).axf -O binary $(PROJECT_NAME).bin

$(PROJECT_NAME).axf : $(OBJS) $(OUTDIR)/startup_stm32f10x.o Makefile
	$(CC) $(CFLAGS) $(OBJS) $(OUTDIR)/startup_stm32f10x.o $(LIBS) $(LINKER_FLAGS)

# Compile: create object files from C source files.
define COMPILE_C_TEMPLATE
$(OUTDIR)/$(notdir $(basename $(1))).o : $(1)
##	@echo
	@echo $$< "->" $$@
	$(CC) -c  $$(CFLAGS) $$< -o $$@
endef
$(foreach src, $(SOURCE), $(eval $(call COMPILE_C_TEMPLATE, $(src))))
#
$(OUTDIR)/startup_stm32f10x.o : $(STARTUP_FILE) Makefile
	$(CC) -c -mthumb $(ALL_ASFLAGS) -O1 $(STARTUP_FILE) -o $(OUTDIR)/startup_stm32f10x.o

clean :
	cs-rm -f $(OBJS)
	cs-rm -f $(OUTDIR)/startup_stm32f10x.o
	cs-rm -f startup_stm32f10x_hd.lst
	cs-rm -f $(PROJECT_NAME).axf
	cs-rm -f $(PROJECT_NAME).map
	cs-rm -f $(PROJECT_NAME).bin

log : $(PROJECT_NAME).axf
	$(NM) -n $(PROJECT_NAME).axf > $(PROJECT_NAME)_SymbolTable.txt
	$(OBJDUMP) --format=SysV $(PROJECT_NAME).axf > $(PROJECT_NAME)_MemoryListingSummary.txt
	$(OBJDUMP) $(OBJS) > $(PROJECT_NAME)_MemoryListingDetails.txt

# Eye candy.
begin:
##	@echo
	@echo $(MSG_BEGIN)

end:
	@echo $(MSG_END)
##	@echo

# Display compiler version information.
gccversion :
	@$(CC) --version
